Outdoor Stainless steel LCD Waterproof Video Digital Kiosk 55inch Interactive Advertising TV Touch Screen Totem

Share to:
sharethis sharing button
1. outdoor lcd monitor:
1.2 The brightness requirement is 2000cd/m2, with ambient automatic light sensing and tempered explosion-proof glass.
1.3 The internal structure is designed and reinforced with reinforcing ribs according to the requirements.
The firmness of the whole machine structure can resist typhoon level.
The material of the machine is made of galvanized steel plate.
The painting process adopts double-layer spraying outdoor powder. fixed.
1.4 The whole machine adopts high-quality cooling fans to dissipate heat, plus lightning protection, overload, overvoltage, overcurrent,
and overtemperature protection equipment, and the structure is designed to prevent rain, dust, and sun exposure.
1.5 Functional requirements: Adopt industrial-grade embedded Android motherboard, support Wifi, RJ45 interface,
4G networking (optional), support simultaneous control of all machines or a single control, and support full HD 1920x1080 decoding.
  • DEDI

Availability:
Quantity:
Panel
Panel Type
32 inch
43 inch
49 inch
55 inch
65 inch
Display Size
393x698.4mm
530x942mm
605x1075mm
681x1210mm
805x1430mm
Appearance Size
482x787.4mm
619x1091mm
685x1149mm
777x1306mm
901x1526mm
Diagonal Aspect Ratio
16:9
16:9
16:9
16:9
16:9
Physical Resolution
1920x10803840x2160
1920x10803840x2160
1920x10803840x2160
1920x10803840x2160
1920x10803840x2160
Display Colors
16.7M
16.7M
16.7M
16.7M
16.7M
Viewing Angle
H178°/V178°
H178°/V178°
H178°/V178°
H178°/V178°
H178°/V178°
Luminance (nits)
2500cd/sqm
2500cd/sqm
2500cd/sqm
2500cd/sqm
2500cd/sqm
Contrast
MEGA DCR
MEGA DCR
MEGA DCR
MEGA DCR
MEGA DCR
Backlit Type
WLED
WLED
WLED
WLED
WLED
Response Time
6ms
6ms
6ms
6ms
6ms
Lifespan
50000 hours
50000 hours
50000 hours
50000 hours
50000 hours
Operation System
Windows 10(option)
CPU: intel core i3, i5, i7
Memory: 4G,8G,16G
Hard Disk: 128G, 256G, 512G
Android
Quad-core, 2G RAM, 16G RAM


Consumption
Power Supply
AC100-240V, 50/60Hz
AC100-240V, 50/60Hz
AC100-240V, 50/60Hz
AC100-240V, 50/60Hz
AC100-240V, 50/60Hz
Max. Consumption
120W
140W
180W
200W
300W
Standby Consumption
<3W
<3W
<3W
<3W
<3W
Output
VGA
1
HDMI
1
Input & Storage
WIFI Module
YES
RJ45
1
USB
1


Appearance
Application condition
Outdoor
Material
Cold-roll steel
Frame Color
Black/white/customization
Installation Type
Wall Mount / Suspend
Dimension Packing
Full wooden box pack
Quality Standard
CE, RoHS, FCC,SGS

01 (320)01 (324)微信图片_20241107092046微信图片_20241107092051微信图片_20250524161333
