Technique Parameter for LCD Panel:
SPECIFICATION & PARAMETER PANEL Panel Type 10.1 inch to 98 inch Active Area Based on screen size(get more information kindly contact with sales) Resolution 1920x1080 FHD/3860x2160 UHD Aspect Ratio 16:09 Contrast Ratio 1400:1 Displaying Color 16.7M/1.06B 68% (CIE1931) View Angle 178°(H) / 178°(V) Response Time ≤ 5ms S-System PAL / NTSC / SECAM Backlight Patented LED module + Constant power components Brightness 1500-7000nits (customized) Life Expectance 60000 Hours
ENVIRONMENT Work Temp -35ºC to 55ºC Storage Temp -45ºC to 60ºC Work/Storage Humidity 5% to 95% FUNCTION Video Format MP4,3GP,MPG,AVI,WMV,FLV,SWF,RMVB,MKV,VOB Image Format JPG,BMP,PNG,TIF,ICO,GIF,TGA Audio Format MP3,WMA,AMR,OGG,AAC,WAV,FLAC,APE OS Android 3288 2G/4G RAM+8G/16G/Other ROM/Window I3,5,7 4G+128G/8G+256/Other Touch screen IR/Capacitive/Nano customized Log Management Supportive to terminal log and playlist log Power Mode Time-setting On or Off | Manual HARDWARE Material cold-rolling metal plate + Special outdoor powder paint Protective Glass 6MM Laminated and Tempered glass Heat Dissipation Fan-cooling/Air conditioning cooling Protective Level IK10/IP55/IP65 I/O Interface WIFI, 4G, USB, SD Card,HDMI Play Mode Plug and play, Network(Remote) Speakers 2*10W Stereo Carton Dimension Based on screen size(get more information can contact with sales) N.W / G.W Based on screen size(get more information can contact with sales) Accessories Remote Control, AC Power Cord, Key, Rack, Instruction, Approval Certificate, Warranty Card Certificates ISO9001/CE/ccc/FCC/RoHS/IP65 POWER Voltage AC 100V - 240V Consumption 380W Standby ≤ 3W
SPECIFICATION & PARAMETER PANEL Panel Type 10.1 inch to 98 inch Active Area Based on screen size(get more information kindly contact with sales) Resolution 1920x1080 FHD/3860x2160 UHD Aspect Ratio 16:09 Contrast Ratio 1400:1 Displaying Color 16.7M/1.06B 68% (CIE1931) View Angle 178°(H) / 178°(V) Response Time ≤ 5ms S-System PAL / NTSC / SECAM Backlight Patented LED module + Constant power components Brightness 1500-7000nits (customized) Life Expectance 60000 Hours
ENVIRONMENT Work Temp -35ºC to 55ºC Storage Temp -45ºC to 60ºC Work/Storage Humidity 5% to 95% FUNCTION Video Format MP4,3GP,MPG,AVI,WMV,FLV,SWF,RMVB,MKV,VOB Image Format JPG,BMP,PNG,TIF,ICO,GIF,TGA Audio Format MP3,WMA,AMR,OGG,AAC,WAV,FLAC,APE OS Android 3288 2G/4G RAM+8G/16G/Other ROM/Window I3,5,7 4G+128G/8G+256/Other Touch screen IR/Capacitive/Nano customized Log Management Supportive to terminal log and playlist log Power Mode Time-setting On or Off | Manual HARDWARE Material cold-rolling metal plate + Special outdoor powder paint Protective Glass 6MM Laminated and Tempered glass Heat Dissipation Fan-cooling/Air conditioning cooling Protective Level IK10/IP55/IP65 I/O Interface WIFI, 4G, USB, SD Card,HDMI Play Mode Plug and play, Network(Remote) Speakers 2*10W Stereo Carton Dimension Based on screen size(get more information can contact with sales) N.W / G.W Based on screen size(get more information can contact with sales) Accessories Remote Control, AC Power Cord, Key, Rack, Instruction, Approval Certificate, Warranty Card Certificates ISO9001/CE/ccc/FCC/RoHS/IP65 POWER Voltage AC 100V - 240V Consumption 380W Standby ≤ 3W
