Ultra-Slim & Modern Design
Featuring an ultra-slim profile of only 50mm, this display combines powerful performance with a sleek, modern appearance. It offers easy installation similar to traditional digital signage, while being lightweight and space-saving for flexible deployment.
TFT Panel | |||
Model | DEDI-32D01 | ||
Panel size | 32inch | ||
Resolution | 2160*3840 (9:16) | ||
Brightness (nits) | 300nits | ||
Orientation | Portrait | ||
Contrast Ratio(Typ.) | 4000:1 | ||
Active Display Area | 699.8(H)× 395.1(V) | ||
Operation Hour | 24/7 | ||
Display color | 16.7M | ||
Visual angle | 178°/178° | ||
Response time | <6.5ms | ||
Touch | PCAP touch optional | ||
Operating system | |||
Operating system | Android | ||
RAM | 2G | ||
ROM | 32G | ||
Input | HDMI*2, USB2.0*2, RJ45, TFcard | ||
HDMI input | 480i, 480p, 576i, 576p, 720p,1080i, 1080P, 2160p | ||
USB | USB*1 | ||
Output | Stereo mini Jack | ||
Headphone Jack | 3.5mm headphone jack, one dual-channel speaker output port. | ||
Speaker | 5W*2 | ||
Appearance | |||
Enclosure color | Grey/Black, customized RAL | ||
Enclosure material | Aluminum Alloy / Metal | ||
Dimension(L*W*D)mm | 731.4*426*42.8mm, wall bracket 8mm | ||
Package dimension | 830*536*160mm | ||
Weight | Screen 6.9kg, bracket 1.4kg | ||
Gross weight | 9.9kg | ||
Vesa mount | 200*200 | ||
Bezel width (mm) | 13.8mm and 12.8mm | ||
Electricity | |||
Power supply | AC100~240V 50 /60 HZ | ||
Maximum power consumption | <60W | ||
Temperature | |||
Working temperature | 0℃ to 40℃ | ||
Storage temperature | -10℃~60℃ | ||
Working humidity | 85% | ||
Storage humidity | 85% | ||
Accessories include | Quick Setup Guide, Warranty Card, Power Cord,Remote Controller (no batteries), wall bracket | ||
