43inch Multi Touch Screen Open Frame Monitor with IR Dual touch,multi touch sreen,SAW Touch for Digital Signage,Advertising,Gaming,Casino,Kiosk,ATM,POS

27inch Multi Touch Screen Open Frame Monitor with IR Dual touch,multi touch sreen,SAW Touch for Digital Signage,Advertising,Gaming,Casino,Kiosk,ATM,POS

DEDI Open Frame LCD Monitor Series products with front bezel series offers flexible options for TFT LCD Panel, touchscreen, signal interface and bracket mounting. The series with standard integrated metal housing and mount bracket, is ideal mounting solution for different embedded application.
DD-27OKN1 is 27'' LCD Monitor with Open frame design, support 27'' IPS Panel 350nits, LED Backlight, 2559x1440 WQHD resolution TFT LCD Screen.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Specifications
Model No.	DD-27OKN1
Description	27'' Open Frame IPS Monitor with No touch, TFT LCD 350nits, 2569 x 1440 WQHD Resolution
Size	27''
Display Area (mm)	596.7(H) x 335.6(V)
Pixel Pitch (mm)	0.2331(H) x 0.2331(V)
Resolution	2569X1440
Brightness	350 cd/m2
Contrast Ratio	1000 : 1(typ)
Backlight	LED Backlight
Viewing Angle	178(H): 178(V)
Display Colors	1.07B colors
Dimension(VxHxT)	Refer Mechanical drawing
Touch Screen
Type	NO touch
Touch Connectors	USB or RS232 (Optional)
Power Information
Power Source	AC 100~240 V, Universal,±10%
Power Consumption	54 W typical, normal operation
Power Management	VESA DPMS Compliant
Display Signals
Plug & Play	VESA DDC 1/2B
Signal Connector	15 pin D-Sub(VGA)/DVI-D
Mechanical
Material	Steel chassis
Mounting	Rear mounting ,VESA Mounting
Certifications
Compliance	CCC,CE,FCC,ROHS
Optional
Touch screen	SAW Optional
High Brightness	800/1000/1500nits Optional
Order Information
AP-27OPLHN1	27'' Open frame LCD Monitor No Touch Screen
AP-27OPLHT1-S	27'' Open frame LCD Monitor with SAW Touch Screen
